Power up to 2.5W
UAS VTX 2.5W 5.8G Video Transmitter
UAS VTX 2.5W 5.8G
A powerful video transmitter for FPV kits with adjustable output power up to 2,500 mW, designed for stable video transmission over long distances.
Features an aluminum heat sink, efficient heat dissipation, and overheating protection, ensuring reliable operation during extended flight.
It supports the ABEFRLHX bands, features a standard 30.5×30.5 mm mounting, is powered by a 2–6S LiPo battery, uses the IRC Tramp protocol, and includes convenient LED indicators for channel and band.
Consultation
Get advice
Please provide your name and phone number, and the UASkyline team will contact you regarding the model you selected.
Technical Specifications
SPECS
Key product specifications with the option to customize for specific orders.
Control protocolIRC Trump
Video formatsCVBS PAL/NTSC
Transmit power — up to 2.5 W
Frequency range4800–6200 MHz
Transmission power level — 25 mW–2.5 W
Connector typeMMCX 50 Ohm
CoolingHybrid
Dimensions40×40×18 mm
Weight42 g
(*) Technical specifications are subject to change based on the order.
Key Features
5.8 GHz Band
IRC Tramp
MMCX 50 Ohm
What is this product designed for?
Strike Missions
For scenarios requiring precision, flight stability, and adaptation to specific payloads.
Interception
Tasks
For rapid response and operation in environments where speed and maneuverability are critical.
Special
Operations
For non-standard missions where the system is configured to meet the operator’s specific requirements.
Reliability and Support
Operator Training
Providing the foundational knowledge needed to work effectively with the system.
Technical Support
Consulting and support after solution delivery.
Adaptation to the task
The ability to customize the system to meet specific requirements.
