Current up to 65A
UAS ESC 65A 6S Speed Controller
UAS ESC 65A 6S
A powerful electronic speed controller for FPV drones, designed for high performance, stable operation, and precise control.
Supports LiPo batteries up to 6S and delivers up to 65A per channel, making it the optimal solution for freestyle, racing, and long-endurance flights.
The ESC supports DShot600, DShot300, and PWM protocols and features built-in protection against overheating, short circuits, and overloads. Its compact form factor and well-designed cooling system make it easy to integrate into most FPV frames.
Consultation
Get advice
Please provide your name and phone number, and the UASkyline team will contact you regarding the model you selected.
Technical Specifications
SPECS
Key product specifications with the option to customize for specific orders.
Operating voltage — 25V MAX, 6S
Current65A
Maximum current80A (10s)
LIPO (Lithium-polymer battery)LIPO 3S-6S
MCU (Microcontroller unit) / MicrocontrollerSilabs BB21 48 MHz
Current sensor / Current sensor0.3 mOhm shunt
External capacitor / External capacitor1000 uF 35 V low impedance
Temperature sensor / Temperature sensoronboard
Format — 4-in-1
Software — BLheli_S
Outer dimensions — 44 × 4 mm
Mounting holes — 30.5 × 30.5 mm
(*) Specifications are subject to change based on the order.
Key Features
Support for 3S–6S
DShot600 / PWM
4-in-1 format
