900/2400MHz
UAS Dual Band ELRS 900/2400 MHz Control Receiver (RX)
UAS Dual Band ELRS 900/2400 MHz RX
An innovative control receiver for FPV systems, designed for stable communication, long range, and reliable operation even in challenging conditions.
It supports two frequency bands, 900/2400 MHz, and uses ExpressLRS, which provides flexibility, compatibility with popular devices, and a stable signal during flight.
Suitable for pilots who value stability, efficiency, and professional-level control of their FPV drone.
Consultation
Get advice
Please provide your name and phone number, and the UASkyline team will contact you regarding the model you selected.
Technical Specifications
SPECS
Key product specifications with the option to customize for specific orders.
RF Frequency / Frequency Range150 MHz–2,500 MHz
Range type / Range typeISM_2.4, FCC_915
IC (Integrated circuit)LR1121 2X
MCU / MicrocontrollerESP32
Connector / ConnectorIPEX 4X
RF power / Signal power100 mW
Operating Voltage4.5V–8.4V
Communication protocolCRSF
Antenna connectorIPEX MHF, 915 MHz 2X, 2400 MHz 2X
Firmware — EXPRESSLRS 3.3
CompatibilityNOMAD GEMINI TX
(*) Technical specifications are subject to change based on the order.
Key Features
ExpressLRS 3.3
CRSF Protocol
100mW RF power
What is this product designed for?
Strike Missions
For scenarios requiring precision, flight stability, and adaptation to specific payloads.
Interception
Tasks
For rapid response and operation in environments where speed and maneuverability are critical.
Special
Operations
For non-standard missions where the system is configured to meet the operator’s specific requirements.
Reliability and Support
Operator Training
Providing the foundational knowledge needed to work effectively with the system.
Technical Support
Consulting and support after solution delivery.
Adaptation to the task
The ability to customize the system to meet specific requirements.
